G1 SIZING AND COMPATIBILITY

SIZE SMALL:

Head tube outside diameter must be 54mm or less
We recommended use with frames that use a press-in headset top cup. This will prevent any compatibility issues from using the G1 with different gyro tabs.
If your frame does not use a press in top cup, you can use gyro tabs that line up with the bottom of the small G1 (69mm) however, gyro tabs are not included and may need to be customized to line up with the width of the bottom of the gyro. Using a vernier caliper is the best way to measure.
Steer tube must have 20mm of extra length

SIZE LARGE

Head tube outside diameter must be 54mm or greater
We recommended use with frames that use a press-in headset top cup. This will prevent any compatibility issues from using the G1 with different gyro tabs.
If your frame does not use a press in top cup, you can use gyro tabs that line up with the bottom of the large G1 (74mm) however, gyro tabs are not included and may need to be customized to line up with the width of the bottom of the gyro. Using a vernier caliper is the best way to measure.
Steer tube must have 20mm of extra length

FEATURES

MTB specific gyro
Made in Canada from domestic 6061 T6 machined aluminum
Low friction / high wear resistance machined delrin bushing
Two sizes available (dependent on outside diameter of head tube)
Available as a full system or gyro only

INTENDED USE

Dirt Jump / Slopestyle
Skatepark / Street

RECOMMENDATIONS

To ensure proper installation, watch our G1 gyro set up video
Recommended use of G1 cables and L1 lever for best set up
Keep bushing lightly lubricated
Have installed by a professional

COMPATIBILITY

The large fits on :

Canyon Stitched
Trek Ticket
Devinci Sabbath
Scott Voltage

The small fits on all other frames if they feature a 44mm zerostack headset cup on top, and steel and aluminum frames

Black Market
Banshee
Chromag
Commensal
Corsair
Dartmoor
Giant
GT La Bomba
Kona
Morpheus
Mongoose
Marin
Rose
Santa Cruz
Specialized
Transition
Pivot
Polygon

If you do not see your frame please watch our install video for how to measure your head tube.
